SPECIFICATIONS
|
Video/Audio Input
|
Details
|
|
IP video input
|
32-ch
|
|
Two-way audio input
|
1-ch, RCA (2.0 Vp-p, 1kΩ)
|
|
Audio Input
|
1-ch, RCA (2.0Vp-p, 1kΩ)
|
|
Network
|
Details
|
|
Incoming bandwidth
|
256Mbps
|
|
Outgoing bandwidth
|
256Mbps
|
|
Remote connection
|
128
|
|
Network Protocol
|
1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
|
|
HDMI output
|
4K (3840 × 2160), 1920 × 1080p, 1600 × 1200, 1280 × 1024,1280 × 720, 1024 × 768
|
|
VGA output
|
1920 × 1080p, 1280 × 1024, 1280 × 720, 1024 × 768
|
|
Audio output
|
1-ch, RCA (linear 1 kΩ)
|
|
Video/Audio Output
|
Details
|
|
Recording Resolution
|
12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
|
|
Audio Output
|
1-ch, RCA (Linear, 1kΩ)
|
|
Synchronous Playback
|
16-ch
|
|
Decoding
|
Details
|
|
Live view / Playback
|
12MP/8MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
|
|
Hard Disk
|
Details
|
|
eSATA
|
1
|
|
SATA
|
4 SATA interface for 4 HDD
|
|
Capacity
|
Up to 6TB capacity for each HDD
|
|
External Interface
|
Details
|
|
Network Interface
|
1RJ-45 10/100/1000Mbps self-adaptive Ethernet interface
|
|
Serial Interface
|
1 RS-485 half-duplex interface
|
|
USB Interface
|
- Front panel: 2 × USB 2.0
- Rear panel: 1 × USB 3.0
|
|
Alarm In
|
16-ch
|
|
Alarm Out
|
4-ch
|
|
POE
|
Details
|
|
Interface
|
16 independent 100 Mbps PoE Ethernet interfaces
|
|
Max. Power
|
200W
|
|
Supported Standard
|
AF and AT
|
Video Compression
|
H.265+, H.265, H.264+, H.264, MPEG4
|
|
General
|
Details
|
|
Power Supply
|
100 to 240 VAC
|
|
Consumption(without hard disk and POE)
|
Up to 20 W
|
|
Working Temperature
|
-10 ºC ~ +55 ºC (+14 ºF~ + 131 ºF)
|
|
Working Humidity
|
10 % ~ 90 %
|
|
Chassis
|
19-inch rack-mounted 1.5U chassis
|
|
Dimensions
|
17.5" × 15.3" × 2.8" (445 mm × 390 mm × 70 mm
|
|
Weight(without HDD)
|
Up to 11 lbs (5 kg)
|
