SPECIFICATIONS
|
Camera
|
Details
|
|
Image Sensor
|
1/3" Progressive Scan CMOS
|
|
Min. Illumination
|
0.01Lux @ (F1.2, AGC ON), 0 Lux with IR
|
|
Shutter time
|
1/3 s to 1/100,000 s
|
|
Lens
|
2.8mm, 4mm, 6mm @ F2.0, angle of view: 106°(2.8mm), 83°(4mm), 55.4°(6mm)
|
|
Lens Mount
|
M12
|
|
Adjustment Range:
|
Pan:0° ~ 360°, Tilt: 0° ~ 75°, Rotation: 0° ~ 360°
|
|
Day& Night
|
IR cut filter with auto switch
|
|
Wide Dynamic Range
|
120 dB
|
|
Digital noise reduction
|
3D DNR
|
|
Compression Standard
|
Details
|
|
Video Compression
|
H.264/MJPEG/H.264+
|
|
H.264 code profile
|
Main Profile
|
|
Video bit rate
|
32Kbps~16Mbps
|
|
Dual Stream
|
Yes
|
|
|
Details
|
|
Max. Image Resolution
|
2688 × 1520
|
|
Frame Rate
|
- 50Hz: 20fps (2688×1520), 25fps(1920×1080), 25fps(1280×720)
- 60Hz: 20fps (2688×1520), 30fps (1920×1080), 30fps(1280×720)
|
|
Image Settings
|
Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser
|
|
BLC
|
Yes, zone configurable
|
|
Network
|
Details
|
|
Network Storage
|
NAS (Support NFS,SMB/CIFS), ANR
|
|
Alarm Trigger
|
Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception
|
|
Protocols
|
- TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP
- PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
|
|
General Function
|
Anti-Flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering
|
|
System Compatibility
|
ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI
|
|
Communication Interface
|
1 RJ45 10M / 100M Ethernet interface
|
|
General
|
Details
|
|
Operating Conditions
|
- -30 °C ~ 60 °C (-22 °F ~ 140 °F)
- Humidity 95% or less (non-condensing)
|
|
Power Supply
|
12 VDC ± 25%, PoE (802.3af Class3)
|
|
Power Consumption
|
Max. 5.5W (Max. 7.5W with ICR on)
|
|
Weather Proof
|
IP67
|
|
IR Range
|
Up to 30m
|
|
Dimensions
|
Φ127×97.5 (5.0” × 3.8”)
|
|
Weight
|
670g (1.5 lbs)
|
