SPECIFICATIONS
|
Camera
|
Details
|
|
Image Sensor
|
1/2.5" Progressive Scan CMOS
|
|
Signal System
|
PAL/NTSC
|
|
Min. Illumination
|
Color: 0.01 lux @(F1.2, AGC ON), 0 lux with IR
|
|
Shutter time
|
1/3 s to 1/100,000 s
|
|
Slow shutter
|
Support
|
|
Lens
|
2.8 to 12 mm
|
|
Lens Mount
|
φ14
|
|
Adjustment Range:
|
Pan: 0° to 360°, tilt: 0° to 100°, rotate: 0° to 360°
|
|
Day& Night
|
IR cut filter with auto switch
|
|
Wide Dynamic Range
|
120 dB
|
|
Digital noise reduction
|
3D DNR
|
|
Focus
|
Motorized VF lens(-Z model)
|
|
Compression Standard
|
Details
|
|
Video Compression
|
H.265+ / H.265 / H.264+ / H.264 / MJPEG
|
|
Video bit rate
|
32Kbps~16Mbps
|
|
Audio bit rate
|
32 to 128kbps
|
|
Triple Streams
|
Yes
|
|
|
Details
|
|
Max. Image Resolution
|
3840 × 2160
|
|
Frame Rate
|
- 50Hz: 20 fps (3840 × 2160), 25 fps (2560 × 1920, 2560 × 1440, 1920 × 1080, 1280 × 720)
- 60Hz: 20 fps (3840 × 2160), 30 fps (2560 × 1920, 2560 × 1440, 1920 × 1080, 1280 × 720)
|
|
Sub Stream
|
- 50Hz: 25fps (640 × 360, 352 × 288)
- 60Hz: 30fps (640 × 360, 352 × 240)
|
|
Third Stream
|
- 50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288)
- 60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240)
|
|
Image Enhancement
|
BLC/3D DNR
|
|
Image Settings
|
Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser
|
|
Target Cropping
|
Support
|
|
ROI
|
Support 1 fixed region for each stream
|
|
Day/Night Switch
|
Auto/Schedule/Triggered by Alarm In
|
|
Network
|
Details
|
|
Network Storage
|
microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
|
|
Alarm Trigger
|
Motion detection, tampering alarm, HDD full, HDD error, network disconnected, IP address conflicted, illegal login
|
|
Protocols
|
- TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP
- PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6
|
|
General Function
|
One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering
|
|
System Compatibility
|
ONVIF (Profile S, Profile G), PSIA, CGI, ISAPI
|
|
Interface
|
Details
|
|
Comms Interface
|
1 RJ45 10M / 100M Ethernet interface
|
|
Alarm
|
1 input, 1 output (max. 12 VDC, 30 mA)
|
|
Alarm Input
|
1
|
|
Alarm Output
|
1
|
|
Video Output
|
1Vp-p Composite Output (75 Ω, BNC)
|
|
On-board storage
|
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
|
|
Reset Button
|
Yes
|
|
Environment Noise Filtering
|
Yes
|
|
Smart Feature-set
|
Details
|
|
Behavior Analysis
|
Line crossing detection, Intrusion detection, Unattended baggage detection, Object removal detection
|
|
Line Crossing Detection
|
Cross a pre-defined virtual line
|
|
Intrusion Detection
|
Enter and loiter in a pre-defined virtual region
|
|
Unattended Baggage
|
Objects left over in the pre-defined region such as the baggage, purse, dangerous materials
|
|
Object Removal
|
Objects removed from the pre-defined region, such as the exhibits on display.
|
|
Recognition
|
Face Detection
|
|
General
|
Details
|
|
Operating Conditions
|
- -30 °C ~ 60 °C (-22 °F ~ 140 °F)
- Humidity 95% or less (non-condensing)
|
|
Power Supply
|
12 VDC ± 25%, PoE (802.3af Class3
|
|
Power Consumption
|
- 12 VDC, 0.92A, max. 11W
- PoE (802.3af, 37V to 57V), 0.22A to 0.35A, max. 12.5W
|
|
Weather Proof
|
IP67
|
|
Impact Protection
|
IK10
|
|
IR Range
|
Up to 30m
|
|
Dimensions
|
Φ 135.8 mm × 145.5 mm (Φ 5.35" × 5.73")
|
|
Weight
|
- With Package: Approx. 1220 g (2.69 lb.)
- Camera: Approx. 1060 g (2.34 lb.)
|
